Description
| MODEL | B61-1001 |
| Standard | EN 54-7 |
| Operating Voltage | 9VDC ~ 28VDC |
| Quiescent Current | ≤60uA |
| Alarm Current | 10mA ≤I ≤ 50mA |
| LED indicator | Red, flashing every 2s ~ 4s when standby; Illuminating when alarm fire |
| Remote indicator output | 10kΩ resistor is required |
| Power-Up Time | ≤ 10s |
| Wiring Method | Polarized two-wire |
| Ingress Protection Rating | IP32 |
| Temperature | -10⁰C ~+ 55⁰C |
| Humidity | ≤95%, non-condensing |
| Dimension | Diameter: 100mm, Height: 43mm (w/out base) |
| Weight | About 120g |
